Neptune™ Outdoor Universal Tilt Wall Mount for 32" to 75" TVs

The Neptune™ Outdoor Universal Tilt Wall Mount is the ideal mounting solution for Neptune™ Shade Series Outdoor TVs. This all-season mount is specially coated with a protective anti-corrosive e-coating that repels against damaging temperature-related and outdoor corrosive elements. In addition to simple installation with a Hook-and-Hang™ design, this mount offers tilt functionality while keeping the TV a mere 2.64" (67mm) from the wall. The One-Touch™ tilt feature offers +15°/-5° vertical tilt movement to lock the TV at your ideal viewing angle. Tamper-resistant hardware deters theft, offering peace-of-mind with every installation and for additional security, the mount has accommodations for optional padlocks.

California Residents Warning: Cancer and reproductive harm - see www.P65Warnings.ca.gov for more information.

  • Features
  • Specs
  • Downloads
  • Hook-and-Hang™ design helps attach enclosure to mount and hold the weight load while fine-tuning adjustments
  • 8" (203mm) of horizontal adjustment for ideal TV position
  • Incremental tilt settings enable the best viewing angle
  • One-Touch™ tilt allows adjustment of +15°/-5° with optional tilt lock in 5° increments
  • Open wall plate allows total wall access, increasing electrical and cable management options
  • Made of corrosion resistant materials for weather resistance
  • Universal mount fits TVs with mounting patterns up to 732 x 405mm (28.84"W x 15.94"H) and up to 600 x 400mm VESA® compliant
  • 2.64" (67mm) from the wall
  • Double stud mounting with 16", 20" & 24" stud placements
  • Tamper-resistant hardware is standard and also has accommodations for optional padlocks
  • Wood, concrete or cinder block mounting hardware included
PRODUCT SPECS

Dimensions (W x H x D)

30.87" x 16.89" x 2.64"-5.51" (784 x 429 x 67-140mm)

Product Weight

8.5lb (4kg)

Load Capacity

175lb (79kg)

Finish

E-Coat Covered with Outdoor Powder Paint

Available Colors

Black

PACKAGING SPECS

Package Size (W x H x D)

32.00" x 3.63" x 10.25" (813 x 92 x 260mm)

Package Ship Weight

10.5lb (5kg)

Package UPC Code

735029322283

Package Contents

Mount and Mounting Hardware

Sell Sheet

User Guide
